Basic Info.
Model NO.
PX-BFC80
Automatic Grade
Fully Automatic
Material Type
Liquid
Filling Valve Head
Multi-Head
Feed Cylinder Structure
Multi-Room Feeding
Dosing Device
Capacity Cup
Filling Principle
Atmospheric Pressure
Packaging Container Lifting Structure
Pneumatic Lifting
Structure
Linear
Packaging
Bottle
Packaging Material
Composite Materials
Accuracy
99%
Advantage
Easy Operation High Efficiency
Transport Package
Strong Wooden Cases
Specification
10-100ml filling machine
Trademark
shanghai PAIXIE
Origin
Shanghai China
HS Code
8422309090
Production Capacity
3000 Bottles Per Hour
Packaging & Delivery
Package Size
800.00cm * 600.00cm * 350.00cm
Package Gross Weight
350.000kg
Product Description
OVERVIEW :
The new PX-BFC80 Smart Automatic flat bottle spray tube cap liquid filling capping machine line is able to fill 3000-5000 cans per hour, depending on fill volume. Easy adjustable for 100-500 ml . The filling station is designed specially suitable for different viscous liquid materials, such as aerosol, oil, perfume, etc. Driven by pneumetic system, filling with high accuracy of ±1%. Insertion station includes closed cabinet with vibrating bowl feed for 10-50 mm diameter caps. No bottle, no filling, inserting or capping.
Features :
1 - Piston pump filling station is contributed to precision and speed control .
2 - For different format changing , here we set scale for measurement which is convenient in operating .
3 - Easy adjust, operator just edit the filling parameter on control pannel to realize all kinds products packing .
4 - Organic glass protection safe door which equipped with induction switch is able to stop machine whenever operator open the door which is good for human protection .
5 - Machines are assembled and tested for easier installation for customer. our technicians are standing by all time for service before and after selling.
MAIN PARAMETERS :
| Model | PX-BFC80 |
| Filling material | Aerosol liquid spray etc |
| Yield(pcs/min) | 50-80 BPM (customized) |
| Filling heads | 1-4 (customized) |
| Filling pump | Piston pump |
| Capping heads | 1-2 (customized) |
| Work voltage | 110/220/380V 50/60HZ (customized) |
| Air presstion | 0.6MPA |
| Filling Accuracy | ±1% |
| Capping rate | 99% |
| Power | 2-3.5KW |
| Driving | Pneumetic system |
| Direction | Left -rigth /right-left |
| Pump volume | 100-500 ml (customized) |
| United size | 1200*900*2000mm |
| Weight | 500kg |
| Material | Contacting parts SS304/SS316 (Optional) |
| Protection | Comprehensive Safety Alarm System |
| Speed controller | Variable Speed Controls |
| Detecting system | Vial Detector & Counter |
