Basic Info.
Model NO.
DDLZ-420
Material Type
Food,Medical Product
Packaging
Blister
Packaging Material
Plastic
Certificate
CE
Voltage
380V
Weight
1700kg
Condition
New
Package
Blister
Under The Film Width
422mm
Transport Package
Professional Export Wooden Case
Specification
6100*1200*1900 mm
Trademark
SCIENCE
Origin
Zhejiang, China
Production Capacity
20 Sets/Month
Product Description
The packaging machine is my factory's latest high-precision equipment, the use of foreign advanced technology machines, absorb our DDLZ series stretching vacuum installed features, innovative design and produce their own automated assembly line packaging machinery, is the first domestic product, completely replace the imported equipment. It applies to all kinds of food, meat, seafood, fruits and vegetables and other products for vacuum, inflatable, plastic stick body / Paper / hard plastic packaging.
Features and functions:
1. Use Panasonic servo motor, touch screen, PLC and other control systems, machine operation easy adjustment.
2. Is equipped with world-class original German vacuum pump, fast, stable quality, durable and reliable.
3. The use of advanced cross-cutting, slitting systems, replacement of easy operation. (Boundless punching save material).
4. Die chute positioning retooling convenient and accurate mold with cooling system.
5. Optical tracking, the choice of color covering film or film for packaging, reduce costs and improve product quality.
6.The consumer products packaging requirements, on the basis of the vacuum can be filled with nitrogen or other packaged mix.
7. Imported wide open chain, for a variety of thicknesses of soft membrane, the dura mater and semi-Dural stretch forming.
8. Packaging appearance, uniform foam quality, good sealing performance.
9. Machine materials, the body part of the whole 304 # stainless steel, aluminum internal frame structure and channel components.
10. Host material part of the assembly on the automatic feeding device, loaded liquid materials.
11.Machines including vacuum, pneumatic automatic adjustment function, vacuum, pneumatic functions can be selected individually synchronized.
12.Laser coders assign a code part, legible, visible and beautiful.
Technical Parameters
Model | DDLZ-420 |
The film width | 392mm |
Under the film width | 422mm |
Vacuum degree | ≤200Pa |
Compressed air | ≥0.6MPa |
Cooling water | ≥0.15MPa |
Power supply | 380V 50HZ/220V 60HZ |
Total Weight | 1700kg |
Dimensions | 6100×1200×1900mm |
Machine parts:
Package during shipment:
FAQ:
1.--Any machine in stock?
No,because the automatic machines are custom-made according to your requirements.
2.--What's the lead time?
The lead time is around 30 days.(From the day we receive the deposit and samples)
3.--Can you help the shipment?Ship from which port?
Yes,we can help to the shipment,just tell us the name of sea port in your side.If by air,it's from Shanghai International Airport.If by sea,it's from Shanghai or Ningbo.And other seaport of China are accepted.
4.--The payment?
By TT and L/C.TT:30% in advance as deposit,70% balance before shipping.
5.--Can we visit factory to check machines firstly,then place order?
Sure,welcome to visit us!
Need more machines details or videos?
Please contact us directly!
