Basic Info.
Type
Double Chamber Vacuum Packing Machine
Object State
Paste, Powdery, Liquid, Solid
Condition
New
Material
Stainless Steel
Raw Material
Food Like Meat Sausage Meatball Vegetables Fruit
Feeding Type
Automatic
Capacity
500-2000kg/H
Dimension
1000*860*1200mm
Weight
480kg
Suitable for
Food Like Meat Sausage Meatball Vegetables Fruit
Machine Name
Vacuum Packing Machine
Advantage
Automatic
Feature
Easy Operation High Efficiency
Transport Package
Wooden Case
Specification
multifunctional
Trademark
INBER
Origin
China
HS Code
8422303090
Production Capacity
1000set/Month
Product Description
Automatic Single Chamber Household Dz400 Vacuum Sealer Dry Fish food Vacuum Packing Machine
Suitable for different raw material:
Main Features
3.Electrical requirement and plug could be custom according to customer requirement.
Specifications:
Suitable for different raw material:
Main Features
1. Double chamber, high efficient.
2.Material of Main Structure: 304 stainless steel.
3.Electrical requirement and plug could be custom according to customer requirement.
4.The products can be prevented from oxidation, going mould,insects or getting damp, thus can be kept fresh for longer time.
5.Can finish the whole programs of vacuum extraction, gas flushing (optional) , sealing, cooling and exhaust automatically.
6.Lid Gasket: The vacuum chamber lid gasket made of high-density material guarantees the sealing performance of the machine in routine work.
The series of vacuum packing machines is featured automatic processing of vacuuming, sealing, cooling, which is used in vacuum packing of food, pharmaceutical aquatic, chemical and electronices industries. It can prevent the products from oxidization and mildew, as well as corrosion and moisture, keeping the quality and freshness and prolonging the storage time.
Detailed description of the method of operation
1. Plug in the power (220V or 380V)
2. Turn on the power button
3. Adjust the pumping time (about 20-30 seconds)
4. Adjust the sealing time (about 3 seconds)
5. Adjust the cooling time (about 3 seconds)
6. Installed items, placed inside the bag sealed
7. Press the top cover to operate the vacuum gauge back to zero to complete the work.
Multi-function:
1.Vacuum+seal
2.Vacuum+Nitrogen(customized)+Seal
3.Seal
4.Count
Specifications: MODEL | DZ400/2SB | DZ500/2SB | DZ600/2SB | DZ700/2SB |
VACUUM CHAMBER SIZE | 400*440*140mm*2 | 570*440*120mm*2 | 600*440*140mm*2 | 725*625*18mm*2 |
SEALING LENGTH | 400MM*2 | 500MM*2 | 600MM*2 | 700MM*2 |
AIR PRESSURE | ≤1Kpa | |||
CAPACITY | 2-4 times/min | |||
POWER SOURCE | AC380V 50HZ 3PH 1.5KW | AC380V 50HZ 3PH 3.5KW | ||
PUMP POWER | 0.75KW | 1.5KW | 2.2KW | 2.25KW |
SEALING POWER | 0.8KW | 1.2KW | 1KW | 1.2KW |
MACHINE SIZE | 990*720*930mm | 1300*740*950mm | 1494*980*1100mm | 1670*980*1100mm |
WEIGHT | 180kg | 235kg | 400kg | 450kg |
