Basic Info.
Model NO.
KF02-L
Application
Cleaning, Detergent, Cosmetics, Drinks, Skin Care Products, Dairy Products, Hair Care Products, Oil
Type
Forming Filling Sealing Machine
Forming Species
Melt Molding
Forming Function
Forming, Filling, Seal
Driven Type
Electric and Pneumatic
Material Type
Liquid
Packaging
Bottles
Packaging Material
Plastic
Name
Sauce Packing Machine
Weight
300kg
Voltage
380V
Certification
CE ISO
Transport Package
Wooden Case
Specification
1400*1000*1850mm
Trademark
KEFAI
Origin
Hubei, China
HS Code
8422303090
Production Capacity
100/Month
Packaging & Delivery
Package Size
140.00cm * 100.00cm * 185.00cm
Package Gross Weight
300.000kg
Product Description
Application
This machine is designed for the automatic packing of liquid, viscous sauce and paste material, it seals adopt three or four side seal method, according to different material, the packing materials adopt different metering device to inject into bags. Cut off methods can use each of flat knife, serrated knife, point marking knife as requirement. And equipped with ease open bags cutting device.KF02-PC VP series mechanical breakthrough adopts localizable high performance double frequency conversion PLC control system, through "man-machine dialogue", make the adjustments for replacing products become simple, accurate and stable, English interface making the setting operations simple, intuitive, and reliable
Main Features
This machine has one set of vertical hot roller sealing device,one set of horizontal hot roller sealing device and one set of horizontal cold roller sealing device.Rolling sealing is adopted:Vertical sealing is chessboard pattern with leak proof,while horizontal sealing is chessboard pattern(or plain seal) with leak proof. Customer can choose magnetic pump for free-flow liquid,Hibar pump for even viscous product,Piston pump for uneven viscous liquid and Rotary pump® for even viscous product continuous feeding.There are three types of cutting functions: plain cutting, sawtooth cutting and perforation cutting.
This machine is also equipped with tear notch for convenient bag opening. PLC control, touch screen displays running status. Vertical sealing unit driven by a variable-frequency motor, realize stepless adjustment of packaging speed within rated range. Horizontal sealing unit driven by servo motor, realize stepless adjustment of bag length within rated range.
The bag length can be set on the Touch screen, and length adjustment is easy and convenient. Intelligent photocell positioning control system with the function of automatic positioning of the first bag.
Eliminate the influence of signal disturbing caused by abnormal eye-mark patterns and bad print of the film, to ensure stable operation. Automatic adjustment function for noneffective cutting, solve the problem of multiple machine-stopping adjustments and waste of film, improving working efficiency and ensuring the good appearance of bags.
specification | item | Specification |
| Length | 45-180mm |
| Width | 30-95mm(3-side seal) 35-100mm(4-side seal) |
| Filling Capacity | 0.5-60mlml(g) |
| Packing Speed | 100-200pcs per min |
| Power | 3kw/ AC380V |
| Dimension | 1400*1000*1850mm(L*W*H) |
| Weight | 450kg |
| Weight | PET/AL/PE,PET/PE,OPP/CPP etc. composite film |
| Parameters of Film Roll | Outer Diameter≤400;Inner Diameter φ75 |
| Standard Filling device | Magnetic Pump/Hibar Pump/Piston Pump/Rotary Pump |
| Standard Cutting method | Plain Cutting,Sawtooth Cutting,Perforation cutting |
| Optional device | Thermal printer,Priniter,Level Sensor,Double layer Hopper,Agitator,Outlet Conveyo |
Company Advantage
Wuhan Kefai Innovation Machinery known as a member of "Wuhan international chamber of commerce" was found in 2007 with the ambition of becoming a premier supplier of filling&packing machine. Over more years of operation, from a humble beginning of infrastructure and staff thanks to our internal constant attempt as well as the support of clients worldwide we have grown and developed continuously to gain significant success in the packaging industry. Our key manufacturing products are automatic food packing machine, liquid filling machine which have been acknowledged in the global market and clients.In another hand, KEFAI also succeed in dealing with other packaging equipment, such as: coding machine,labeling machine,carton sealing machine , capping machine etc.. Customers who are looking for filling machine and packing machine from China will find the comfort and satisfaction at KEFAI as we usually attach special importance to the quality of the products. Understanding that quality is the vitality which affirms our reputation in such highly competitive environment we commit to supply customers best quality products every time for a unique principle: "Customer's satisfaction is our passion"
FAQ 1. who are we?
We are based in Hubei, China, start from 2014,sell to Domestic Market(32.00%),Central America(15.00%),Western Europe(10.00%),
Northern Europe(8.00%),North America(7.50%),South America(7.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Southern Europe(3.50%),Africa(3.00%),Mid East(3.00%),Oceania(1.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Bottle Filling Machines,Sachet Packaging Machine,VFFS packing machine,Packing solutions,Bag packing machine
4. why should you buy from us not from other suppliers?
Make Your Packaging Easier ! One-stop Solution for Automatic Packaging Engineering. Professional 12 years's R&D team, and
strict quality control systems to make sure top quality! OEM service make your any demand become realistic and easy.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
